WRD5180GQX Road Marking Removal / Car Wash

WRD5180GQX (Heavy Duty High-Pressure Water Removal)

WRD5180GQX

The WRD5180GQX is a 280MPa heavy-duty high-pressure water removal vehicle, equipped with fully imported key components, fully automatic front-end operations, three-stage filtration safety protection, and a patented slurry water recovery system. It features high reliability, efficient removal, and safety and environmental protection, making it suitable for efficient removal operations of high-grade road markings.

Advantages and Features

Advantages and features

High-pressure, high-efficiency removal and excellent operational capability

Using a 280MPa high-flow ultra-high-pressure water pump, equipped with dual cleaning discs and ruby nozzles, achieving high operational efficiency (45-65㎡/hour). With a single water refill, it can operate continuously for 3.5 hours, meeting high-intensity construction demands.

Stable and reliable system architecture design

Core components (engine, high-pressure water pump, hydraulic rotary joint, etc.) use original imported parts, and apply imported hydraulic transfer systems and new hydraulic cooling technology, effectively improving operational stability, with a maintenance interval of 600-1000 hours.

Automation construction and safety assurance functions

Equipped with a fully automatic front-end operation device, it can be remotely controlled from the cab without the need for ground personnel, significantly improving construction safety. The equipment has a built-in three-stage filtration and automatic protection system, which can automatically issue a warning and stop operation in abnormal conditions such as excessive pressure or filter blockage.

Environmental Protection Operations and Intelligent Residue Recovery

Equip a patented slurry recovery system to ensure that no dust, debris, or wastewater is generated during construction. The slag box is equipped with high-pressure automatic cleaning and automatic tipping functions to achieve efficient waste residue handling, meeting green and environmentally friendly construction standards.

Long-lasting and durable anti-corrosion and rust-resistant performance

The whole vehicle adopts high-grade electrophoretic coating or composite electroplating treatment, featuring outstanding corrosion and rust resistance, capable of maintaining structural stability under various environmental conditions and extending the service life of the equipment.

Intelligent Integration and Precise Control

Equipped with a visual operation platform, it monitors equipment operating parameters in real time, and, combined with constant pressure control and a hydraulic cooling system, ensures a damage-free clearing process with high operational precision, comprehensively improving construction quality and control convenience.

Basic product parameters

Comprehensive understanding of product information

WRD5180GQX (Heavy Duty High-Pressure Water Removal)

The WRD5180GQX cleaning vehicle (heavy-duty high-pressure water removal) is a highly reliable device that uses a high-pressure water pump and imported key components, an automated front-end removal device, a three-stage filtration, and a safety protection system.

Product Model Category

WRD5180GQX-HPB/WRD5180GQX-HPC/WRD5180GQX-HPD

Main Pump Machine Brand

GREATROAD/JETSTREA/HAMMELMANNM

Clear water tank capacity

4m³

Time for one water addition operation

3.5h

Filtering device

1-10μm three-stage filtration

Recycling device

-30Kpa

Engine model and power

Weichai WD10D255E10 255 kW or Dongfeng Cummins QSB6.7 194 kW

Main pump pressure

280Mpa

渣箱容积

4.7m³

Fuel tank capacity

300L

Clearing device

Double cleaning disc, ruby nozzle

Product Model Category

WRD5180GQX-HPB/WRD5180GQX-HPC/WRD5180GQX-HPD

Engine model and power

Weichai WD10D255E10 255 kW or Dongfeng Cummins QSB6.7 194 kW

Main Pump Machine Brand

GREATROAD/JETSTREA/HAMMELMANNM

Main pump pressure

280Mpa

Clear water tank capacity

4m³

渣箱容积

4.7m³

Time for one water addition operation

3.5h

Fuel tank capacity

300L

Filtering device

1-10μm three-stage filtration

Clearing device

Double cleaning disc, ruby nozzle

Recycling device

-30Kpa
